JBL

Club 3020

Details
Item# CLUB3020-
Variations
  • Select Color
Product Actions
Add to cart options

Additional Information
Club coaxial and component speakers let legendary JBL sound fit in more vehicles thanks to a compact design and high sensitivity for high performance.
At a Glance:
  • Acoustically damped, UV-resistant polypropylene cone
  • Plus One™ woofer cone architecture
  • PEI balanced dome tweeters
  • High-sensitivity design
  • Reduced critical dimensions
  • Competitive pricing
What's in the Box:
  • 1 pair of coaxial speakers
  • Foam mounting tape
  • Owner’s manual
Club coaxial and component speakers bring legendary JBL sound to more vehicles. Their compact design means they’ll fit in most cars and trucks on the road, while high sensitivity delivers outstanding performance, even when they’re powered by factory stereos. Rugged polypropylene cones with the Plus One™ design deliver hard-hitting bass and long performance life. PEI balanced dome tweeters play smooth highs. Available in a range of standard sizes—3", 4", 5-1/4", 6", 6-1/2", 6" x 8" and 4" x 6" coaxial, 6" x 9" 3-way, and 5-1/4", 6-1/2", and 6" x 9" component—they’re the perfect upgrade from factory speakers.
Product Features:
  • Acoustically damped, UV-resistant polypropylene cone
    Every Club speaker’s woofer cone is designed to deliver clean, non-resonant sound quality, while standing up to the demanding heat and humidity of the car environment.
  • Plus One™ woofer cone architecture
    Harman’s patented (US patent #7,548,631) Plus One™ cones provide more overall speaker-cone area than other cones in its class — the result is higher sensitivity, increased low-frequency output and greater musical character.
  • PEI balanced dome tweeters
    Club speakers play smooth, clear high frequencies with excellent dispersion, thanks to the PEI balanced dome tweeters.
  • High-sensitivity design
    Club speakers’ efficiency produce plenty of sound from the power they’re fed, making them ideal for any application, even when they’re driven by relatively low-powered factory stereos.
  • Reduced critical dimensions
    Club speakers are available in a range of standard sizes, and feature a compact design that allows them to fit in just about any vehicle on the road today. That means signature JBL sound in more vehicles.
  • Competitive pricing
    Club speakers provide signature JBL sound at affordable prices.
Plus One® Technology

Plus One carbon-injected cones provide more overall speaker-cone area than other cones in its class.

Legendary JBL Sound

You don't have to venture far from home to experience the legendary power of the JBL sound. Complete 5.1 home theater sound. Includes 4 satellite speakers, a center channel and room-shaking subwoofer.

Highlights:
Manuals & Downloads:
General Specifications:
Impedance (ohms)
3
Power Handling
20W RMS, 60W peak
Sensitivity (@ 2.83V)
89dB
Audio Specifications:
Frequency Response
90Hz – 20kHz
Club 3020 is rated 5.0 out of 5 by 2.
Rated 5 out of 5 by from Great tweeter! I just baought these for a 2012 Toyo Camry. They fit and sound beautiful. Super happy with my speakers.
Date published: 2017-08-23
Rated 5 out of 5 by from Perfect upgrade for Ram 1500's with Alpine Read some reviews decided to try them to upgrade the terrible factory speakers in my 17 Ram with Alpine preminum sound. There perfect. Sound amazing
Date published: 2018-01-04
  • y_2018, m_11, d_19, h_4
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.9
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_2
  • loc_en_GB, sid_club3020-, prod, sort_[SortEntry(order=RELEVANCE, direction=DESCENDING)]
  • clientName_harmanaudio

Hello, I have a Toyota Scion tC 2011, I want to know if Club3020, GX302 or GTO329 can fit in the front doors in the original bracket for mid position, because there are not too many space. Original speaker size are 3.5 inch with 3inch hole in the bracket.

Asked by: StanK7
Hi! Unfortunately, we do not have any information on this vehicle, so we are unable to say whether or not the speakers would fit your car. However, these speakers are designed to fit on most car models, if not, you may need to have minor modifications.
Answered by: Nick F
Date published: 2018-06-29

Hi I have a 2007 vw caddy. I want to fit new dash speakers but have trouble with depth around 35mm. Will these fit or can you suggest some

Asked by: Rich1984
Hi. The GTO 329 has 35 mm mounting depth, so it is slightly more shallow than the Club 3020. We have no 3" that features less mounting depth. One way to solve this is of course to use a spacer between the panel and the speaker, but there may be limitations set by a speaker grill that prevent this. I hope this helps.
Answered by: Bo Harman
Date published: 2018-05-02

Hi there! I´ll mod an in dash sealed enclosure for the gx302 but can't find the Vas and Q parameters to do the calculation. Would you know this information or the ideal enclosure volume? Thanks!

Asked by: fabiosantos25
These speakers are designed to be direct replacements for stock 3.5" car speakers. They do not need a box behind them. However, if you'd like to put a box behind them, and improve the performance, a simple sealed enclosure just big enough to hold the speaker, with roughly 1/2" of space behind the magnet will be a great box.
Answered by: Bryan at Customer Service
Date published: 2017-12-02

Will these speakers easily fit in a 1992 Mazda Miata Headrest system?  Is it plug and play or will it require special mounting and wiring?

Asked by: Miata92
Yes. According to the data we have CLUB3020 would fit your car. NOTE: After-market car speakers will require little or no modification for installation.
Answered by: Joe G at Customer Service
Date published: 2017-12-02

Where in the car do these speakers belong? I am looking for two rear deck speakers for a 2004 Pontiac Grand Am GT Coupe.

Asked by: jsmielewski
Probably the CLUB 3020 would fit your lower front door but with minor modifications. If you require Rear deck speakers, I would recommend one of the following JBL speakers: Stage 9603, GT7-96, Club 9600C, Club 9630.
Answered by: Joe G at Customer Service
Date published: 2017-12-02

Welches Gehäusevolumen wäre angebracht um den besten Klang zu erreichen?

Asked by: Chris23
Hallo. Vielen Dank für Ihr Interesse an unsere Produkte. Wir lassen Ihnen in Kürze weitere Informationen per E-mail zukommen, um Ihre Anfrage bestmöglich zu beantworten. Vielen Dank für Ihren Verständnis.
Answered by: Teodor
Date published: 2017-12-02

Amir, can you explain the difference in terms of tech specs and sound quality of the JBL Club 3020 vs GX302. I need this to make a decision on replacing factory in dash speakers for a Toyota HL. I need a qualitative details than just tech specs which I kn

Asked by: Dealzguy
While we always say that how a speaker sounds to an individual is subjective, when used in the same application (same amplification, crossover, gain, location) the GX302 is expected to perform better by quickly looking at its specifications - Frequency Response: GX 302 90Hz-21kHz / CLUB 3020 90Hz-20kHz Sensitivity: GX 302 89 dB / CLUB 3020 86.5 dB Watts (RMS): GX 302 25W / CLUB 3020 20W This shows us that the GX 302 can handle more power and can play higher frequencies, meaning at casual applications where both will be driven with the same power at the same frequency (i.e. 20W @ 10kHz), the GX 302 will not be as strained as the CLUB 3020 would be. In a nutshell, the GX has better frequency response, will play louder with less power, and will handle more power. Sonically, it is our opinion that the GX also has a more neutral sound than the CLUB series.
Answered by: Ren at Customer Service
Date published: 2017-12-02

How many speakers come in the box? Is this a price for each speaker or a pair?

Asked by: swist
Hi Thanks for the question. The box contains 1 pair of Club 3020 drivers. (2 drivers)
Answered by: Mogens
Date published: 2017-12-02
