JBL

Club 6500c

Details
Item# CLUB6500C-
Variations
  • Select Color
Product Actions
Add to cart options

Additional Information
Club coaxial and component speakers let legendary JBL sound fit in more vehicles thanks to a compact design and high sensitivity for high performance.
At a Glance:
  • Acoustically damped, UV-resistant polypropylene cone
  • Plus One™ woofer cone architecture
  • PEI balanced dome tweeters
  • High-sensitivity design
  • Reduced critical dimensions
  • Competitive pricing
What's in the Box:
  • 1 pair of woofers
  • 1 pair of tweeters
  • 1 pair of crossovers
  • 1 pair of tweeter surface mount accessories
  • 1 pair of tweeter flush mount accessories
  • 1 pair of tweeter nuts
  • 1 pair of tweeter flat washers
  • 1 pair of woofer adapter rings
  • 1 pair of woofer grilles
  • 6 tweeter mounting screws
  • 8 small woofer mounting screws
  • 8 large woofer mounting screws
  • 8 crossover mounting screws
  • 8 speed clips
  • Foam mounting tape
  • Owner’s manual
Club coaxial and component speakers bring legendary JBL sound to more vehicles. Their compact design means they’ll fit in most cars and trucks on the road, while high sensitivity delivers outstanding performance, even when they’re powered by factory stereos. Rugged polypropylene cones with the Plus One™ design deliver hard-hitting bass and long performance life. PEI balanced dome tweeters play smooth highs. Available in a range of standard sizes—3", 4", 5-1/4", 6", 6-1/2", 6" x 8" and 4" x 6" coaxial, 6" x 9" 3-way, and 5-1/4", 6-1/2", and 6" x 9" component—they’re the perfect upgrade from factory speakers.
Product Features:
  • Acoustically damped, UV-resistant polypropylene cone
    Every Club speaker’s woofer cone is designed to deliver clean, non-resonant sound quality, while standing up to the demanding heat and humidity of the car environment.
  • Plus One™ woofer cone architecture
    Harman’s patented (US patent #7,548,631) Plus One™ cones provide more overall speaker-cone area than other cones in its class — the result is higher sensitivity, increased low-frequency output and greater musical character.
  • PEI balanced dome tweeters
    Club speakers play smooth, clear high frequencies with excellent dispersion, thanks to the PEI balanced dome tweeters.
  • High-sensitivity design
    Club speakers’ efficiency produce plenty of sound from the power they’re fed, making them ideal for any application, even when they’re driven by relatively low-powered factory stereos.
  • Reduced critical dimensions
    Club speakers are available in a range of standard sizes, and feature a compact design that allows them to fit in just about any vehicle on the road today. That means signature JBL sound in more vehicles.
  • Competitive pricing
    Club speakers provide signature JBL sound at affordable prices.
Plus One® Technology

Plus One carbon-injected cones provide more overall speaker-cone area than other cones in its class.

Legendary JBL Sound

You don't have to venture far from home to experience the legendary power of the JBL sound. Complete 5.1 home theater sound. Includes 4 satellite speakers, a center channel and room-shaking subwoofer.

Highlights:
Manuals & Downloads:
General Specifications:
Power Handling
60W RMS, 180W peak
Sensitivity (@ 2.83V)
92dB
Impedance (ohms)
3
Audio Specifications:
Frequency Response
55Hz – 20kHz
Club 6500c is rated 4.0 out of 5 by 1.
Rated 4 out of 5 by from Great value for the price! I installed these a week ago. The previous speakers I had, cost more than I paid for my JBL Club 6500 speakers. At the time (10 years ago) they were high quality premium speakers w larger magnets. Obviously technology has made improvements to the size and performance of speakers and I couldn't be happier with the overall quality of sound and price that I paid for my JBL speakers.
Date published: 2017-12-13
  • y_2018, m_11, d_19, h_4
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.9
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_1
  • loc_en_GB, sid_club6500c-, prod, sort_[SortEntry(order=RELEVANCE, direction=DESCENDING)]
  • clientName_harmanaudio

hallo. ik heb de club 6500c in mijn auto . word de kwaliteit van de set beter als je er een versterker tussen zet?

Asked by: Stijn1996
Hi Stijn, Dat is heel afhankelijk van de autoradio welke je in de auto hebt. Helaas kunnen wij je hierin niet adviseren, en wil ik je aanraden om dit bij een inbouw-specialist na te vragen
Answered by: Kay Harman
Date published: 2018-11-05

does this set come with an amp

Asked by: Faythe
No. Amps are sold separately. You can check them out at https://www.jbl.com/car-amplifiers/
Answered by: Mario at Customer service
Date published: 2018-11-02

Hi I am currently running a set of jbl 6500c club in van I am now looking to purchase a jbl stage 810 sub and locate this in the van to, the question I need help with is which would be a good amp to run these to get the best from them. regards Mike

Asked by: t5mike
Hi, and thank you for supporting JBL! I recommend JBL Club 4505 for your setup. You can bridge the four main channels to have 2x130 W into 4 Ohms, and you will have the sub channel with 320 W to the 4 Ohm 810 woofer. That will make an impressive system.
Answered by: Bo Harman
Date published: 2018-10-12

Hey JBL, could you tell me the impedance of the woofer and tweeter independently please? I am looking for replacements for my Harman Kardon Mini which has its own dedicated outputs so won't be using the Cross over supplied. Kind regards,

Asked by: Wod7
Hi, and thank you for your interest in JBL! I am sorry, but we do not have individual specs for combination sets. And also please note that the crossover network is made for this specific purpose, with these two exact drive units. We do not have specs for crossover frequency and steepness of the flanks either, so you are totally on your own. All warranty will also be void if you do not use the standard crossovers. The only way I can see you can do this is to use a simple multi-instrument to measure DC resistance, then use this as a coarse guide for the impedance. If you read 3.5 Ohms, at least you will know that this is not an 8-Ohm unit. I know that this measurement is not completely correct, and if you want, you can of course set up a real impedance-measuring circuit. You can find them on the net. Also, you can run a sinus sweep through the crossover with the drive units connected, and note the levels on paper that you can read off a sound level meter, freely available as an app for your phone. I hope this helps.
Answered by: Bo Harman
Date published: 2018-09-14

do i need to buy a wiring kit separat for this system or does all the wires neede for instalation come with the box

Asked by: Andr34s
Hi, and thank you for your interest in JBL! In the box you will find wires for the tweeters, to connect to the crossover networks. Wires to connect the head unit to the crossover, and from the crossover to the woofers, must be purchased separately, or are already in the car (head unit to crossover). This is because the lengths needed vary a lot from installation to installation. I hope this helps.
Answered by: Bo Harman
Date published: 2018-10-06

Does this speaker fits the rear passenger door and do they come in pair?

Asked by: Jman213
Yes, This speaker comes in pair however, for us to know if it would fit in your car, we may need to work with you directly. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Dan E
Date published: 2018-08-13

Why is the woofer + terminal connected to the crossover - terminal? should I follow the diagram on this page ? www.jbl.com/car-audio-systems/CLUB+6500C.html

Asked by: LarryG
We would like to work with you directly to help you with your issue. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Mario at Customer service
Date published: 2018-07-15

I listen to techno and progressive house mostly. I already have a JBL bass tube 1300W. Should I go for this or the GTO 609c for the front doors of Honda Amaze? Please suggest!!

Asked by: Avikk
We would like to work with you directly to help you with your issue. Please submit a case request at https://www.jbl.com/support-contact.html and the Customer Service Team will be more than happy to assist you.
Answered by: Mario at Customer service
Date published: 2018-07-17
